Power Supply

: 220/110VAC+10% 50/60Hz (HP4 just for 220V power supply)

Power Consumption

:3VA

Mounting Mode

: Panel Mount

Ambient Humidity, temperature

: 85% RH, 0-50

Timing Range

: 0.01-99.99S,0.1-999.9S,1-9999S,1-99M59S,0.01-99.99M,0.1-999.9M

: 1-9999M,1-99H59M,0.01-99.99H,0.1-999.9H,1-9999H

Timing Accuracy

: +0.1-+0.05sec

Reset Mode

: Panel reset, External Connection reset, Auto Reset or Power OFF Reset can be chosen

Input Signal

: low level effective

Terminal Capacity

:3A/250VAC or 6A/30VDC

Pulse Interference (AC)

: +1.8KV

Dielectric


: AC 1500V 1min

Insulation Impedance

: DC 500V -100M
