Temperature and Humidity Transmitter

Name: Temperature and Humidity Transmitter
Brand: MICON AUTOMATION SYSTEMS PVT. LTD.
Price: 6000 INR
Availability: InStock

Price 6000 INR/ Box

Get a Price/Quote

MOQ : 1 Box

Temperature and Humidity Transmitter Specification

Features
Wall-mounted, Compact, High stability, Anti-interference

Operating Voltage
12~36V DC

Interface Type
RS485 Modbus / 4-20mA / 0-10V

Power Supply
AC 220V / DC 24V

Temperature
-40C ~ +120C

Response Time
3 s

Humidity
0~99.99% RH

Measuring Range
Temperature: -40 to 120C, Humidity: 0 to 99.99% RH

Accuracy
Temperature: 0.5C, Humidity: 3% RH

Max Height
35 mm

Application
Environmental Monitoring, HVAC, Greenhouse, Industrial Automation

Equipment Type
Temperature and Humidity Transmitter

Port Size
120*85*35mm

Display Type
LCD Digital Display

Mounting Type
Wall Mounted

Resolution
0.01C / 0.01% RH

Automation Grade
Automatic

Usage
Temperature and humidity transmitter

Machine Weight
180 g

Control Mode
Digital/Automatic

Protection Class
IP65

Output Signal
Analog & Digital

Sensor Type
Digital CMOS

Storage Temperature
-40°C ~ +120°C

Life Span
>10 years

Cable Length
1.5 m

Operating Humidity
0~99.99% RH

Sampling Rate
2 seconds

Material
ABS Plastic Housing

Temperature and Humidity Transmitter Trade Information

Minimum Order Quantity
1 Box

FOB Port
Courier

Supply Ability
100 Boxes Per Week

Delivery Time
7 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
100 % safety Guarantee

Main Domestic Market
All India

About Temperature and Humidity Transmitter

K-Hoat Make Temperature and Humidity Transmitter

Adhering to the legal business policies, we are engaged in manufacturing, supplying and exporting Humidity Transmitter. This equipment is used for monitoring humidity & air temperature in food industries, pharmaceutical industries, libraries, meteorological environment, ware houses, equipment room and storehouses. Moreover, this is applied to industrial automation process researching and monitoring. Furthermore, this Humidity Transmitter is one the best digital meter that is serving its purpose better than those of conventional ones.

Application:

KH706 is digital temperature and humidity sensor, widely used for air temperature and humidity monitoring in Medicines, food, meteorological environment, libraries, warehouse or storehouse, equipment room etc and also for industrial automation process monitoring and researching area.

Features:

Safe guide built-in to ensure system safety.
Standard RS-485 Communication port: based on standard MODBUS-RTU protocol.
Wireless communication network can be achieved through current 220 V electricity network, supporting standard MODBUS-RTU protocol. Transmitting distance can be up to 1500m without obstacle band, supporting multi-signals, without interferes with multi-modules transmission.
Adopts original imported digital type temperature and humidity sensor, high measuring accuracy and high stability.
Wall or duct type, optional.

Power	12VDC ~24VDC
Output	0~5VDC or 4-20mA
Range T	-20~80°C ; H:0~100%
Accuracy T	±.0.3°C.;H:+-3%RH(25DC,0%~100%)
Size	120x 85 x35mm

Precision Monitoring for Demanding Environments

Engineered for accuracy, this transmitter measures temperature from -40C to +120C and humidity from 0 to 99.99% RH, with a precise 0.5C and 3% RH accuracy. The resolution of 0.01 units ensures even subtle changes are captured, making it indispensable for sensitive applications like greenhouses, laboratories, and manufacturing plants.

Durable Build with User-Friendly Features

The ABS plastic enclosure is IP65 rated for dust and water resistance, providing reliable performance in demanding conditions. Designed for easy wall mounting, the unit features a bright LCD digital display for straightforward operation. Anti-interference design and automatic digital control further streamline use and maintenance.

FAQs of Temperature and Humidity Transmitter:

Q: How do I install the temperature and humidity transmitter?

A: The device is designed for easy installation as a wall-mounted unit. Simply affix it to a suitable flat surface in your monitoring area, connect the 1.5 m cable to your system, and integrate it with your existing analog or digital data interface, such as RS485 Modbus, 4-20mA, or 0-10V. The ABS plastic housing and IP65 rating allow installation both indoors and in protected outdoor locations.

Q: What applications is this transmitter suitable for?

A: This transmitter is ideal for environmental monitoring in HVAC systems, greenhouses, industrial automation, and other settings requiring precise climate control. Its broad measuring range and robust protection make it a versatile solution for monitoring temperature and humidity in both commercial and industrial environments.

Q: When should I replace the transmitter or its sensor?

A: With a life span exceeding 10 years, the transmitter is built for long-term reliability. Regular inspections are recommended, but sensor replacement is generally not necessary unless exposed to extreme contamination or physical damage. Ensure quick replacement if performance accuracy noticeably decreases.

Q: Where can the transmitter be used given its protection class?

A: The IP65-rated housing protects against dust and low-pressure water jets, making it suitable for use in dusty or humid environments, such as factories, agricultural facilities, or indoor and semi-outdoor installations. It should not be submerged or used in areas subject to continuous direct water exposure.

Q: How does the automatic control mode benefit my application?

A: The digital/automatic control mode enables seamless integration with automation systems, reducing the need for manual adjustment. This feature allows for real-time climate regulation, improving operational efficiency, minimizing errors, and supporting hands-off operation in stable processes.

Q: What is the process for connecting to different output signals?

A: Select the output type that matches your control systemanalog (4-20mA or 0-10V) or digital (RS485 Modbus). Wire the transmitter following the included schematic diagram and supply the appropriate power (AC 220V or DC 24V). The device will deliver real-time, accurate data compatible with your automation and data logging equipment.

Q: What are the benefits of using a digital CMOS sensor in this transmitter?

A: Digital CMOS sensors provide high-speed, highly accurate readings with minimal drift over time. This ensures the transmitter delivers stable, precise temperature and humidity measurements, offering reliability for critical applications and reducing long-term calibration and maintenance requirements.
