ATC-840 USB To RS-422 Converter

Name: ATC-840 USB To RS-422 Converter
Brand: MICON AUTOMATION SYSTEMS PVT. LTD.
Price: 2100 INR
Availability: InStock

Price 2100 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ATC-840 USB To RS-422 Converter Specification

Capacity
Supports up to 32 RS-422 devices

Female End Type
DB9 female (provided via adapter if needed)

Voltage Rating
300V

Pairs
2 pairs

Material
Copper

Male End Type
USB Type A male

Connector Type
USB to RS-422 converter

Temperature
Operating -20C to 70C

Connector
USB Type A male (PC side), DB9 male (RS-422 side)

Application
Industrial data communication, serial device connectivity

Number of Conductor
4

Jacket Material
PVC

Insulation
PVC

Wire Gauge
24 AWG

Sheild
Yes, shielded cable for noise immunity

Outer Diameter
5.0 mm

Length
1.2 meter (standard)

Color
Black

Cable Type
Shielded twisted pair

Flame Resistance Level
UL94V-0

Cable Length
1.2 meter

Supported OS
Windows XP/7/10, Linux

Weight
80 grams

Data Rate
Up to 1 Mbps

Driver
Plug & play, no external driver required on latest Windows and Linux

Signal Direction
Automatic send/receive switching

Protection
15KV ESD protection

Mounting Type
Desktop/Portable

LED Indicator
Transmit/Receive activity

RS-422 Pinout
Full duplex, 4-wire

Case Material
ABS Plastic

Power Supply
Bus-powered via USB

ATC-840 USB To RS-422 Converter Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About ATC-840 USB To RS-422 Converter

ATC-840 USB To RS-422 Converter Specifications:

Warranty	1year
Model Number	ATC-840
Connector Type	DB9
Cable Length (m)	1
Power (W)	Port Powered
Color	Black
Brand	ATC
Minimum Order Quantity	1 Piece

Robust Design with Superior Noise Immunity

Built with an ABS plastic case and shielded twisted pair cable, the ATC-840 offers excellent resistance against electrical noise and physical impacts. Its flame-resistant PVC insulation (UL94V-0 rated) and shielded construction ensure safe and stable data transmissions, making it ideal for harsh industrial environments.

Effortless Plug & Play Connectivity

Connecting serial devices is streamlined with the ATC-840. Simply plug into a USB portno additional drivers are necessary on the latest Windows and Linux platforms. Automatic send/receive signal switching and clear LED indicators further simplify deployment and monitoring.

Versatile Industrial Applications

Whether in automation, manufacturing, or laboratory setups, the ATC-840 USB to RS-422 Converter bridges PCs with serial equipment. Supporting full duplex RS-422 over a 1.2-meter cable and capable of handling up to 32 devices, its ideal for demanding industrial and commercial data exchange.

FAQs of ATC-840 USB To RS-422 Converter:

Q: How does the ATC-840 USB to RS-422 Converter connect to different devices?

A: The ATC-840 connects to your PC via a USB Type A male connector and to RS-422 devices using a DB9 male plug. If you require a DB9 female connection, an adapter can be provided. This setup supports full duplex, 4-wire communication for consistent data transfer.

Q: What operating systems are supported by this converter and is special driver installation required?

A: The converter is compatible with Windows XP, 7, 10, and Linux. On the latest service pack versions of these operating systems, its plug and playno external drivers are necessary.

Q: When should I use this converter and what are its typical applications?

A: The ATC-840 is ideal whenever you need to connect a modern computer to legacy or industrial RS-422 equipment. Typical uses include industrial automation, serial device connectivity, or any scenario requiring stable, long-distance, high-speed serial data communication.

Q: Where can this converter be mounted, and is it easily portable?

A: Designed for both desktop and portable applications, the ATC-840s compact, lightweight (80 g) construction, and durable ABS plastic case make it suitable for use in offices, industrial control rooms, or for field service.

Q: What process should be followed to set up the ATC-840 for data communication?

A: Simply connect the USB end to your PC and the DB9 end to your RS-422 device. The converter automatically switches between send and receive modes, and the LED indicator displays data transmission and reception activity. No complex configuration is needed.

Q: What protection features does the ATC-840 offer for device and data safety?

A: The ATC-840 provides 15KV ESD protection to safeguard connected devices from electrostatic discharge, and includes shielded cabling for immunity to electrical noise. The flame-resistant and durable casing further protects the converter in demanding environments.

Q: What are the key benefits of using the ATC-840 USB to RS-422 Converter?

A: Key benefits include simple, driverless operation on modern platforms, robust data integrity through advanced shielding and ESD protection, high-speed serial data transfer up to 1 Mbps, and support for up to 32 connected RS-422 devices simultaneously.
