MICON Touch Screen HMI

Name: MICON Touch Screen HMI
Brand: MICON AUTOMATION SYSTEMS PVT. LTD.
Price: 5000.00 INR
Availability: InStock

5000.00 INR/Box

Get a Price/Quote

Product Details:

Output Voltage 5V DC (For peripherals)
Rated Voltage 24V DC
Phase Single Phase
Operating Temperature 0C to 50C
Frequency 50/60 Hz
Protection Level IP65 (Front Panel)
Humidity 10% - 90% RH (Non-Condensing)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

MICON Touch Screen HMI Price And Quantity

Minimum Order Quantity 1 , , Box
Price 5000.00 INR/Box

MICON Touch Screen HMI Product Specifications

Rated Voltage 24V DC
Output Voltage 5V DC (For peripherals)
Condition New
Humidity 10% - 90% RH (Non-Condensing)
Operating Temperature 0C to 50C
Phase Single Phase
Efficiency >85%
Processing Type Digital
Power Consumption 8W Max
Function Touch Panel Operation, Data Display, Input Control
Voltage 24V DC
Power Mode DC Powered
Dimension (L*W*H) 154 x 92 x 35 mm
Main Material ABS Plastic
Protection Level IP65 (Front Panel)
Mounting Type Panel Mount
Frequency 50/60 Hz
Input Current 350 mA
Accessories Mounting Clips, User Manual, Cables
Application Industrial Automation, Machine Control

MICON Touch Screen HMI Trade Information

Supply Ability 100 , , Box Per Week
Delivery Time 7 Days

Product Description

MICON Make Touch Screen HMI (M700L)

M700L is economical high performance version of HMI model M77A, it is has only one serial port, NO SD card supported.

Main Board: RISC CPU 400 MHZ, 128M FLASH, 64DDRAM

Display Size: 7 inch

Resolution: 800x480 TFT LCD: 65536 Colors

Interface: Support RS-232/RS-485/RS-422, one serial Port.

Storage: U Disk

General Specifications

Display Size: 7inch True TFT (154.0W x 85.9Hmm)

Resolution: 800X480 pixels Color 65536 Colors

Brightness: 300cd/m2

Backlight: LED

Touch Panel: 4 lines Precision Resistance (Surface Hardness 4H)

Backlight Life: 50000 Hours

CPU: 32-bit 400MHz RISC

Storage And Memory: 128M FLASH + 64M DDRAM

Formula And RTC: 256KB+Real Time Clock

Printing Port: Serial Printing/USB Printing

Program Download: One USB SLAVE Interface

Communicating Port: COM1:RS232/RS422/RS485

Electrical Specifications

Rated Power: Under 5W

Rated Voltage: DC24V

Voltage Range: 12?28VDC

Voltage Interval Allowed: Under 5ms

Insulation: 20M Under 500VDC

Withstand Voltage: 500V AC for 1 minute

Structure Specifications

Shell "">Shell Material: ABS Plastic

Shape Size: 212WX146HX36Dmm

Installation Size: 192Wx138Hmm

Weight: 0.6kg

Environmental Specifications

Work Temperature: -10~60^oC

Work Humidity: 10~90%RH (No Condensation)

Storage Temperature: -20~70^oC

Storage Humidity: 10~90%RH (NO Condensation)

Shockproof Test: 10 ~ 25 Hz (X,Y,Z Orientation 2G/30 minutes)

Cooling Method: Natural Air Cooling

Products Certifications

Degree Of Panel Protection: Conform IP65 Authentication

CE Conform EN61000-6-2, 2005, EN61000-6-4, 2007 Standard

FCC Compatibility: Conform FCC Class A

Advanced User Interface

The 7-inch TFT LCD touch screen of the MICON HMI provides vibrant and precise data visualization, allowing operators to control and monitor equipment efficiently. Its user-friendly touch panel supports reliable input, making it ideal for various industrial processes.

Durability and Reliability

Crafted with a robust ABS plastic housing and IP65-rated front panel, the HMI withstands tough conditions such as dust, water splashes, and temperature variations. The backlight boasts a 50,000-hour lifespan, ensuring prolonged operational dependability.

Flexible Connectivity Options

With support for RS232, RS485, USB Host, and optional Ethernet ports, the MICON HMI seamlessly integrates into existing automation systems, enabling easy communication between devices. Its ample memory allows efficient data storage and processing.

FAQs of MICON Touch Screen HMI:

Q: How does the MICON Touch Screen HMI enhance industrial automation processes?

A: The MICON HMI streamlines control and monitoring with its intuitive 7-inch resistive touch screen, allowing operators to interact directly with machines. Its clear visual display and responsive input help increase efficiency, reduce downtime, and facilitate real-time decision-making across industrial environments.

Q: What are the connectivity options available with this HMI?

A: This HMI supports multiple communication ports, including RS232, RS485, USB Host, and optional Ethernet. These ports enable flexible integration with other devices, PLCs, and network systems, ensuring smooth data exchange and system interoperability.

Q: When is this HMI suitable for deployment in industrial applications?

A: The MICON HMI is ideal for use in challenging industrial settings that require robust human-machine interfacessuch as manufacturing plants, automation systems, and machine control installationsthanks to its durable build, IP65 front panel, wide operating temperature range, and stable performance.

Q: Where can the MICON HMI be mounted and what accessories are included?

A: This device is designed for panel mounting, making it suitable for control panels and industrial equipment. It comes with essential accessories, including mounting clips, a user manual, connection cables, and everything needed for hassle-free installation.

Q: What software is supported, and how does it facilitate configuration?

A: MICON Touch Screen HMI is configured using MiconConfig software, which is compatible with Windows operating systems. The software offers a straightforward interface for customizing screen layouts, function assignments, and communication settings for your application.

Q: What benefits does the IP65-rated front panel offer?

A: The IP65 front panel delivers significant protection against dust, water splashes, and harsh industrial environments. This feature ensures the HMIs long-term reliability and reduces the risk of downtime due to environmental factors.
